Dàn lạnh Cassette 1 hướng WindFree SamSung AM071NN1DEH/EU
Liên Hệ
- Model :AM071NN1DEH/EU
- Bảo hành:24 tháng
- Công suất: 7.1 Kw / 24.200 btu
- Kiểu máy:Âm trần Cassette 1 hướng thổi
- Tính năng:Inverter
- Xuất xứ:Korea
- Tình trạng:Còn hàng
Thông số kỹ thuật dàn lạnh AM071NN1DEH/EU :
| Type | Wind-Free 1Way Cassette | ||||
| Model | AM071NN1DEH/EU | ||||
| Power Supply | Φ, #, V, Hz | 1,2,220-240,50 | |||
| Mode | – | HP/HR | |||
| Performance | Capacity (Nominal) | Cooling 2) | kW | 7.10 | |
| Btu/h | 24,200 | ||||
| Heating 2) | kW | 8.00 | |||
| Btu/h | 27,300 | ||||
| Power | Power Input (Nominal) | Cooling 1) | W | 80.00 | |
| Heating 2) | 80.00 | ||||
| Current Input (Nominal) | Cooling 1) | A | 0.40 | ||
| Heating 2) | 0.40 | ||||
| Fan | Type | – | Crossflow Fan | ||
| Motor | Output x n | W | 54 x 1 | ||
| Air Flow Rate | H/M/L (UL) | CMM | 17.00/15.50/14.00 | ||
| l/s | 283.33/258.33/233.33 | ||||
| External Pressure | Min / Std / Max | mmAq | – | ||
| Pa | – | ||||
| Piping Connections | Liquid Pipe | Φ,mm | 9.52 | ||
| Φ, inch | 3/8″ | ||||
| Gas Pipe | Φ,mm | 15.88 | |||
| Φ, inch | 5/8″ | ||||
| Drain Pipe | Φ,mm | VP20 (OD 25,ID 20) | |||
| Field Wiring | Power Source Wire | mm2 | 1.5 ~ 2.5 | ||
| Transmission Cable | mm2 | 0.75 ~ 1.5 | |||
| Refrigerant | Type | – | R410A | ||
| Control Method | – | EEV INCLUDED | |||
| Sound | Sound Pressure | High / Mid / Low | dB(A) | 42.0/39.0/36.0 | |
| Sound Power | Cooling | 60.0 | |||
| Dimensions | Net Weight | kg | 13.50 | ||
| Shipping Weight | kg | 17.30 | |||
| Net Dimensions (W×H×D) | mm | 1200 x 138 x 450 | |||
| Shipping Dimensions (W×H×D) | mm | 1435 x 224 x 525 | |||
| Panel Size | Panel model | – | PC1BWFMAN | ||
| Panel Net Weight | kg | 5.00 | |||
| Shipping Weight | kg | 7.00 | |||
| Net Dimensions (W×H×D) | mm | 1410 x 35 x 500 | |||
| Shipping Dimensions (W×H×D) | mm | 1473 x 124 x 568 | |||
