Thông số kỹ thuật dàn lạnh AM017NN1PEH/EU :
Type | Wind-Free 1Way Cassette | ||||
Model | AM017NN1PEH/EU | ||||
Power Supply | Φ, #, V, Hz | 1,2,220-240,50 | |||
Mode | – | HP/HR | |||
Performance | Capacity (Nominal) | Cooling 2) | kW | 1.70 | |
Btu/h | 5,800 | ||||
Heating 2) | kW | 1.90 | |||
Btu/h | 6,500 | ||||
Power | Power Input (Nominal) | Cooling 1) | W | 24.00 | |
Heating 2) | 24.00 | ||||
Current Input (Nominal) | Cooling 1) | A | 0.14 | ||
Heating 2) | 0.14 | ||||
Fan | Type | – | Crossflow Fan | ||
Motor | Output x n | W | 27 x 1 | ||
Air Flow Rate | H/M/L (UL) | CMM | 4.80/4.30/4.10 | ||
l/s | 80.00/71.67/68.33 | ||||
External Pressure | Min / Std / Max | mmAq | – | ||
Pa | – | ||||
Piping Connections | Liquid Pipe | Φ,mm | 6.35 | ||
Φ, inch | 1/4″ | ||||
Gas Pipe | Φ,mm | 12.70 | |||
Φ, inch | 1/2″ | ||||
Drain Pipe | Φ,mm | VP20 (OD 25,ID 20) | |||
Field Wiring | Power Source Wire | mm2 | 1.5 ~ 2.5 | ||
Transmission Cable | mm2 | 0.75 ~ 1.5 | |||
Refrigerant | Type | – | R410A | ||
Control Method | – | EEV INCLUDED | |||
Sound | Sound Pressure | High / Mid / Low | dB(A) | 28.0/26.0/24.0 | |
Sound Power | Cooling | 46.0 | |||
Dimensions | Net Weight | kg | 8.00 | ||
Shipping Weight | kg | 10.50 | |||
Net Dimensions (W×H×D) | mm | 740 x 135 x 360 | |||
Shipping Dimensions (W×H×D) | mm | 895 x 223 x 435 | |||
Panel Size | Panel model | – | PC1MWFMAN | ||
Panel Net Weight | kg | 2.60 | |||
Shipping Weight | kg | 4.20 | |||
Net Dimensions (W×H×D) | mm | 900 x 25 x 420 | |||
Shipping Dimensions (W×H×D) | mm | 958 x 112 x 482 |
